Drywall Panel Lift, Manual Master 410

• Placement height: 0,69 m.
• Min. height: 1,40 m.
• Max. height: 4,10 m (4,50 m with extension)
• Extension: optionol
• Weight: 53 kg.
• Capacity: 80 kg.
• Wheels (braked): 3 x Ø 160 mm (3)
• Plate rotatable: 360° rotatable (6 fixing points)
• Horizontal: yes
• Vertical: till 35°
• Maximum board dimensions: 1,22 x 2,44 m.
• Minimum board dimensions: -
• Plateau: yes
• Wheelbase [m]: 1,02 x 1,02 x 1,02

Panel Carrier 40 - 110 mm

Opus Mini Work Light

Luminous power	1800 Lumen
Angle reflected beam	180°
Color temperature	4000 K
Power	24 W
Power socket	1x
Power switch	no
Voltage	220-240 V AC
Dimensions	423 x 215 x 139 mm.
Weight	2,5 kg.
Impact resistant	IK 08
Protection class	IP 54

Light output comparable to a 300 W halogen light.

Window-frame-adjustment-row andlarge model

Drywall panel lift, SEA-360 semi automatic

• Placement height: 0,89 m.
• Min. height: 1,66 m.
• Max. height: 3,60 m.
• Extension: n. a.
• Weight: 39 kg.
• Capacity: 65 kg.
• Wheels (braked): 3 x Ø 100 mm (2 braked).
• Plate rotatable: no
• Horizontal: yes
• Vertical: till 25°
• Maximum board dimensions: 1,2 x 3. 6 m.
• Minimum board dimensions: 0,15 x 0,6 m.
• Plateau: no
• Wheelbase [m]: 0,98 x 0,98 x 0,98
• Operation: automatically and manually

Drywall panel lift, SEA-450 semi automatic

• Placement height: 0,84 m.
• Min. height: 1,61 m.
• Max. height with extension: 4,50 m.
• Extension: integrated, and included.
• Weight: 53 kg.
• Capacity: 80 kg.
• Wheels: 3 x Ø 125 mm (2 braked):
• Plate rotatable: yes
• Horizontal: yes
• Vertical: wall mounting till 90°
• Maximum board dimensions: 1,2 x 3. 6 m.
• Minimum board dimensions: 0,15 x 0,6 m.
• Plateau: yes
• Wheelbase [m]: 1,06 x 1,06 x 1,06
• Operation: automatically and manually
